Level Plus liquid level transmitters utilize the inherent advantages of magnetostrictive technology to provide the product level, interface level, and temperature measurement of a tank from one process opening. Accurately measuring multiple process variables from one opening lowers the installed costs of adding feedback to a storage tank or process vessel.
- 4 to 20 mA Analog Output with HART®
- Two Channel Output
- 3-in-1 Measurement
- Product
- Interface
- Temperature - No Scheduled Maintenance or Recalibration
- High Accuracy and Repeatability
- AMS Aware
- Explosion-proof and/or Intrinsically Safe
|
|
 |
Kontakt Hydex vedrørende MTS Temposonics® MC420 liquid level sensors
| Type |
|
Magnetostrictive position sensor |
|
|
| Output |
|
4-20 mA / HART |
|
| Design |
|
Sanitary / rigid / flexible |
|
| Parameter |
|
Level / Interface / Temperature |
|
| Measuring range |
|
Rigid: 508-7620 mm
Flexible: 3048-12192 mm |
|
| Linearity |
|
0,02 % F.S. |
|
| Approval |
|
PTB/ATEX/CSA
FM
3-A |
|
| For mer informasjon |
|
Klikk her --- Datablad --- Produktoversikt |
|
